DCS10-3/16″-4MM-A
Manufacturer
Ruland
Description
0.1875" X 4mm Bores
0.590" (15.0mm) Od, And 0.719" (18.3mm) Length
Clamp Single Disc Coupling
Accommodates Angular Misalignment And Axial Motion
Anodized Aluminum Hubs, Stainless Steel Disc Springs
0.590" (15.0mm) Od, And 0.719" (18.3mm) Length
Clamp Single Disc Coupling
Accommodates Angular Misalignment And Axial Motion
Anodized Aluminum Hubs, Stainless Steel Disc Springs
Still have other questions?
Please contact our sales managers or request a call they are ready to solve any of your questions.
(800) 228-8895 Request a callSpecifications
Brand
Ruland
Conflict Minerals
Compliant
O.D. (D)
0.590 in (15.0 mm)
Material
Aluminum
Bore (B1)
0.1875 in
Bore (B2)
4 mm
Keyway
No
B2 Max Shaft Penetration
0.354 in (9.0 mm)
Bore Tolerance
+0.001 in / -0.000 in (+0.03 mm / -0.00 mm)
B1 Max Shaft Penetration
0.354 in (9.0 mm)
Screw Material
Alloy Steel
Screw Finish
Black Oxide
Forged Clamp Screw
M2
ISO 9001:2015
Certified
REACH
Compliant
RoHS3
Compliant
Note
Stainless steel hubs are available upon request.
Length (L)
0.719 in (18.3 mm)
UNSPC
31163008
Static Torque
15 lb-in (1.7 Nm)
Hex Wrench Size
1.5 mm
Maximum Speed
10000 RPM
Temperature
-40°F to 200°F (-40°C to 93°C)
Country of Origin
USA
Shaft Tolerance
+0.0000 in / -0.0005 in +0.000 mm / -0.013 mm
Balanced Design
Yes
Number of Screws
2 ea
Tariff Code
8483.60.8000
Dynamic Torque Non-Reversing
7.5 lb-in (0.85 Nm)
Dynamic Torque Reversing
3.75 lb-in (0.43 Nm)
Torsional Stiffness
50 lb-in/Deg (5.6 Nm/Deg)
Angular Misalignment
0.5 deg
Parallel Misalignment
0.000 in (0.00 mm)
Axial Motion
0.002 in (0.05 mm)
Seating Torque
0.6 Nm
Recommended Hex Key
Metric Hex Keys
