HS003CT1LLBG/GLP42

HS003CT1LLBG/GLP42

Manufacturer
TPI
Description
17 Mm X 35 Mm X 10 Mm
Angular Contact Bearing
15° Contact Angle
Single - Universal Matched
$73.60 / each
Get Volume Pricing

Special pricing for OEMs and high volume users.

Request Quote
in list
Please check the entered value
Quote list updated
Still have other questions?

Please contact our sales managers or request a call they are ready to solve any of your questions.

(800) 228-8895 Request a call

Specifications

Bore Diameter (d)
17 mm
Outside Diameter (D)
35 mm
Width (B)
10 mm
Contact Angle
15° contact angle
Bearing Arrangement
Single - Universal Matched
Brand
TPI
Precision
P42
Ring Material
SUJ2 Steel
Ball Material
SUJ2 Steel
Preload
Light Preload
Dynamic Load(Cr)
0.66 lbs
Static Load(C0r)
0.58 lbs
Speed Rating Grease
47900 rpm
Speed Rating Oil
73700 rpm
Closure
Rubber Seal
