MCL-14-AN

Custom price
Placeholder
MCL-14-AN
Manufacturer
Ruland
Description
14mm Bore; 30mm Od, 11mm Width
One-piece Shaft Collar
Anodized Aluminum
Clamp Style
$22.93 / each
Add to Cart
Still have other questions?

Please contact our sales managers or request a call they are ready to solve any of your questions.

(800) 228-8895 Request a call

Specifications

Brand
Ruland
O.D. (D)
30 mm
Material
Anodized Aluminum
Bore (B1)
14 mm
Bore Tolerance
+0.050 mm / +0.012 mm
Screw Material
18-8 300 Series Stainless Steel
Screw Finish
Bright
Forged Clamp Screw
M4 x 14
ISO 9001:2015
Certified
REACH
Compliant
RoHS3
Compliant
Conflict Minerals
Compliant
Tariff Code
8483.60.8000
Number of Screws
1 ea
Screw Location (R)
11.00 mm
Seating Torque
2.5 Nm
Hex Wrench Size
3.0 mm
Temperature
-40°F to 200°F (-40°C to 93°C)
Country of Origin
USA
Finish Specification
Anodize
Shaft Tolerance
+0.000 mm / -0.013 mm
UNSPC
31162811
Clearance Diameter (C) MAX
33.7 mm
Material Specification
2024-T351 Bar
Width (W)
11 mm
Reference drawing
